Programmable Touch Screen Controller

• Various selectable controls and adjustment via touch screen panel
• Dynamic control function for logic, volume, message play, status display
• Connect up to 2 RWD-AIO per OCTO Jr
• Connect up to 32 RWD-AIO per UAP G3
• 1 x RCA line input, 1 x RCA line output and 1 mic input on the front panel
• CAT5/CAT6 connection with RJ45 connector
• Control functions can be programmed by software
• RS485 for 3rd party control

Electrical

• Power consumption: 4.11 Watts (24 VDC, 1.5 A)
• Phantom power: +24 VDC (max. 15 mA)
• OCTO-Link port: 24 VDC @ 0.2 A maximum

Audio Characteristics

• Frequency response: 0±1 dBu (20 ~ 20k Hz @ 0dBu)
• THD+N: <0.015 % (@1k Hz, 20k Hz BW @ 12 dBu gain, -6 dBu In)
• A/D-D/A converts: 24 Bit
• Sample rate: 48k Hz
• EIN (XLR): -120 dBu (20 ~ 20k Hz @ 42 dBu gain, 150 ohm)
• EIN (RCA): -80 dBu (20 ~ 20k Hz @ 0 dBu gain, 150 ohm)
• Dynamic range: >98 dBu (20 Hz ~ 20k Hz, 24 dBu gain, a weighted)
• Crosstalk: <-70 dBu @ 0 dBu gain, 0 dBu In (channel to channel @ 10k Hz)

Mechanical

• Dimensions (WxHxD): 140 x 106 x 40 mm
• Weight: 0.4 kg

Bar/Restaurant Application

Office Application

Huddle Room Application

Conference Room Application

Classroom Application

House of Worship/Church Application
