Wallmount Paging Console

CD-8DF / CD-16DF

  • - Compatible with BOUTIQUE Systems
  • - 8/16 keys as single or group zone selection
  • - EVAC button
  • - Talk button for PTT (Push-To-Talk) or latching mode
  • - 1 monitor speaker
  • - Fireman microphone
  • - EN54-16 certification

  • Wallmount Paging Console (0)
  • Wallmount Paging Console (1)
  • Wallmount Paging Console (2)

Compatible with Boutique Systems, the CD-8DF and CD-16DF wall-mount paging consoles with 8/16 keys and EVAC buttons are designed with an encased IP30 heavy-duty metal box with a lockable cover. The 8/16 keys can set to act as single or group zones selection, event triggering, recording, message playing button, etc. All the settings are configured via web browser. The talk button can also be programmed for PTT (Push-To-Talk) or latching mode. In addition, they are equipped with a fireman microphone and an evacuation button.

Up to 16 paging consoles can be connected to BTQ-SL8, and 32 on BTQ-VM4/VM8/SG8; the wiring can be daisy-chain or in redundant loop. The maximum communication cable length between the controller/secondary units and paging consoles is 250m (820 ft.) via STP CAT5/6 cable with shielded RJ45 connector. CD-8DF and CD-16DF are also eco-friendly products with extremely low power consumption (<1.5W) during standby mode.

  • Wall-mount metal enclosure with lockable cover
  • Up to 16 paging consoles can be connected to BTQ-SL8, and 32 on BTQ-VM4/VM8/SG8; the wiring can be daisy-chain or in redundant loop
  • Control, management and monitor via web browser
  • AGC (Automatic gain control) function

Electrical

  • DC power input: 21 - 29 VDC
  • Power consumption: CD-8DF/CD-16DF
    • Full power: 5 W/6 W
    • Standby mode: 1 W/1.5 W

Audio Characteristics

  • A/D-D/A bit resolution: 24 bit
  • Sampling rate: 48k Hz
  • Frequency response: 20 Hz ~ 20k Hz (±1 dB) @ 0 dBu
  • SNR: > 85 dB
  • THD+N: < 0.2 % @ 26 dB gain, -26 dBu (1k Hz) in
  • Max. speaker SPL: 90 dBA @ 3m
  • Max. mic SPL: 105 dBA @ 3m

Mechanical

  • Dimensions (W x H x D)
    • CD-8DF: 329 x 187 x 101 mm
    • CD-16DF: 349 x 241 x 101 mm
  • Weight
    • CD-8DF: 3.4 kg (7.5 lb)
    • CD-16DF: 4.1 kg (9 lb)
  • Colour: RAL7016
