IP Based Intercom Microphone

TERRA-K

  • - Multi-function Ip based microphone
  • - Designed for Full Duplex intercom and paging
  • - One built-in button
  • IP Based Intercom Microphone (0)
  • IP Based Intercom Microphone (1)
  • IP Based Intercom Microphone (2)
  • IP Based Intercom Microphone (3)

The TERRA-K is an IP, PoE multi-function microphone console, designed for full duplex intercom and paging using Unicast, Multicast & Broadcast over LAN/WAN. It comes with a gooseneck microphone and built-in monitor loudspeaker.

It can also be used with TerraManager to perform a recording function. Its pre-chime and post-chime can be configured via the web browser interface. It also has 2 LED indications and one button on the front panel, which displays device status and triggers certain functions.


Model:

  • TERRA-K: IP based Intercom Microphone
  • High quality gooseneck microphone and built-in loudspeaker (2.5 W)
  • Web browser interface for device  management and monitor
  • PoE or 24 VDC power supply (if PoE is not available)
  • Support G.711, G.722, G.726, G.727, G.729, MP3 audio codec and AAC+ decoder
  • Paging to pre-defined zones
  • Pre-recorded announcement and dynamic zone paging via TerraManager
  • Full duplex intercom with Noise Reduction
  • Push-to-talk button, Talk LED and Power LED
  • Power consumption: 3.12 W
  • Weight: 0.8 Kg
  • Dimensions (DxHxW): 125 x 350 135 mm

Terra-K application


Type File Name Download
Catalogue
[PDF] TERRACOM_Catalogue
Brochure
[PDF] TERRACOM_Brochure
Datasheet
[PDF] TERRA-K_Datasheet
