Contact I/O Terminal over IP

TERRA-8IO Vox@

- Solution for applications requiring additional analog Inputs/Outputs

- Triggering of event for sound systems based on Vox@ range

  • Contact I/O Terminal over IP (0)
  • Contact I/O Terminal over IP (1)

TERRA-8IO Vox@ is an IP terminal with 8 contacts inputs and 8 relay outputs, making it an ideal solution for applications requiring lots of analog Inputs/Outputs like industrial and home automation or monitoring contact closures.

The device is directly connected to the network thanks to a standard RJ45 interface. A built-in web browser interface allows simplified control and programming of the unit.

Contact inputs can be programmed as logic, selector or analog mode for actions triggering, source selection or gain adjustment. Contact inputs and relay output are fully programmable and can be managed locally or via a VNB control protocol.

The RS232 interface can be used for IP tunneling between a PC and a device such a sensor for tele-monitoring.

  • TERRA-8IO Vox@: 8 contact inputs + 8 relay outputs
  • 8 contact inputs
  • 8 relay outputs N.O.
  • VNB Framework control protocol for interaction with other devices (including HTTP)
  • Event scheduler
  • Vox@ range and Vox@Net compatible
  • Ethernet interface RJ45 10/100 Mbit/s with PoE
  • RS232 for third party control
  • LED: Power, Status, Ethernet Link
  • PoE or external 24 VDC power supply
  • Power consumption: 2 W
  • Weight: 0.42 Kg
  • Dimensions (DxHxW): 104 x 32 x 109 mm
