Alarm Input Interface

URGP

  • - Compatible with IDA8 systems
  • - Additional Alarm inputs
  • - RS232/RS485 secured link to the IDA8 matrices
  • - EN54-16 certified
  • Alarm Input Interface (0)
  • Alarm Input Interface (1)
  • Alarm Input Interface (2)

The URGP is a contact interface extension unit to the IDA8 Public Address and Voice Evacuation Systems. Each URGP provide additional alarm inputs. Each input is monitored and can be programmed to trigger a digital audio message into a specific zone or group of zones. The URGP is linked to the System units through an RS232 / RS485 monitored serial link.

Two models are available:

  • URGP-32I/2O: 32 Alarm inputs and 2 fault outputs
  • URGP-16I/16O: 16 Alarm inputs and 16 fault outputs
  • Desktop enclosure
  • Secured RS232 / RS485 link to controllers and slaves
  • URGP-32I/2O : 32 alarm inputs and 2 fault outputs
  • URGP-16I/16O : 16 alarm inputs and 16 fault outputs
  • Status and fault indicator
  • EN54-16 certified (URGP-32I/2O)

Electrical

  • Voltage: 18 - 26 VDC
  • Power consumption: 30 mA

System / Evacuation inputs

  • Contact mode: 5 VDC
  • Voltage mode: -6 dBu
  • Monitoring resistor: 4.7k Ohms

System connection

  • Cable type / Length: CAT-5 (FTP) / 100 m (max)

Mechanical

  • Dimensions (H x W x D): 44 x 140 x 75 mm
  • Weight: 0.5 Kg
  • Color: RAL7016

Environmental

  • Operating temperature: -5° C to +55°C
  • Storage temperature: -40° C to 70° C
  • Relative humidity: 15% to 90%
  • Air pressuire: 600 to 1100 h Pa
  • IP rating: 30
