Touch-screen Secure Paging Console

PSS-AS

  • - Compatible with IDA8 Systems
  • - 168 software keys across 14 pages for zone or group of zones selections
  • - 1 monitor speaker
  • - Call-paging
  • - Message broadcasting
  • - DSP matrix parameter control
  • - EN54-16 certification
  • Touch-screen Secure Paging Console (0)
  • Touch-screen Secure Paging Console (1)
  • Touch-screen Secure Paging Console (2)
  • Touch-screen Secure Paging Console (3)
  • Touch-screen Secure Paging Console (4)

The PSS-AS is a paging console for IDA8 systems which allows call-paging, message broadcasting and DSP matrix parameter control over a secured monitored bus. The back-lit full-color touch screen is designed for user-friendly operation and offers a total of 168 software keys across 12 pages for zone or group of zones selection. Each key contains a color-changing field indicating that the zone is occupied by a different process. All paging parameters for site operation can be pre-programmed such as zones can be assigned, named, grouped to different buttons, message triggering, level control, setting of pre-call chime. The message and the chime can also be stored in the PSS console. In addition, fader control, button control and event control can also be pre-configured.

  • Secured CAT-5 link to controllers and slave units
  • Supervision of microphone capsule
  • Monitoring loudspeaker
  • 5” TFT full color touch-screen, 800 x 480 pixels
  • LCD display: 14-pages x 12 keys
  • 3 LED indicators: Power/General Fault/Evacuation active
  • Power, status and fault indicator
  • Status information access from the touch screen panel
  • EN54-16 certified

Electrical

  • Mains power supply
    • Voltage: 18~30 VDC PoE: 44~57 VDC
    • Power consumption: 250 mA

Audio

  • Frequency response: -3 dB @ 200 Hz to 18 kHz
  • THD: < 1% @ 1 kHz
  • Output level Max: 6 dBu
  • Noise gate threshold: -84 dBu ~ –24 dBu
  • Attack time: 8 ms
  • Release time: 100 ms
  • Output impedance: 100 Ohm
  • Monitoring speaker
    • Impedance: 4 Ohm
    • Output power: 1 W @ 1 Khz
    • Frequency response: -3 dB @ 200 to 12 kHz
  • Headset
    • Connector: 3.5 mm mini-jack

Mecanical

  • Console (H x W x D): 80 x 250 x 140 mm
  • Microphone length: 280 mm
  • Weight: 1.1 kg
  • Colour: RAL7016
  • Material: Metal back, PVC top and sides
